Package: Car
Version: 2.0.3
Description: Unified logic for Mercedes GLC. Normalizes sensors (Windows/Doors), wrapper switches, and Status Notifications.
Executive Summary
The Car package provides a unified interface for the Mercedes GLC, leveraging the mbapi2020 integration. It normalizes proprietary attribute data (e.g., window status codes, specific lock states) into standard Home Assistant binary sensors and device classes. The package includes a comprehensive automation suite (notify_car_status_glc) that monitors critical vehicle states—such as charging progress, pre-entry climate control, and fluid warnings—and dispatches actionable notifications via the notify_smart_master script.
Process Description (Non-Technical)
How It Works
- Real-time Monitoring: The system continuously checks the status of your car's doors, windows, and locks. You can instantly see if the car is secure or if the engine is running.
- Remote Control: You can lock or unlock the doors and close the windows directly from your dashboard. Additionally, the "Pre-entry A/C" switch allows you to heat or cool the car before you leave.
- Smart Notifications:
- Charging: Receive alerts when the car is plugged in, when charging starts (with estimated completion time), and when the battery is full.
- Safety & Maintenance: The system watches for warning signs like low tire pressure, low brake fluid, or low washer fluid and sends critical alerts to your phone if attention is needed.
Integration Dependencies
- Mercedes Me 2020 (mbapi2020): Cloud integration for Mercedes-Benz.
- Type: HACS Integration
- Role: Device Attributes & Commands
- script.notify_smart_master: Central notification router.
- Type: Script
- Role: Alerting
Dashboard Connections
This package powers the following dashboard views:
- CAR: This view provides a comprehensive interface for the Mercedes GLC ("The Car"). It features a visual representation of the car's state (Home/Away, Engine On) using dynamic picture elements. Key controls include pre-entry climate scheduling via a scheduler card and door/window management. The dashboard also monitors critical telemetry such as fuel level, EV battery charge, tire pressure, and lock status, visualizing them with color-coded indicators and Mushroom cards. (Uses 1 entities)
- Home: The Home dashboard serves as the central information hub. It features a large clock and family calendars, alongside detailed weather forecasts. Key home stats are highlighted, including real-time energy prices, power usage, and the status of major appliances like the dishwasher and washing machine. The view also provides a high-level overview of the entire house, displaying camera feeds and status summaries for all key rooms (Sauna, Bathroom, Bedroom, etc.) using 'Streamline' area cards. (Uses 1 entities)
Architecture Diagram
The architecture relies on the mbapi2020 integration to poll data from the Mercedes Cloud. The Car package acts as a transformation layer, converting complex attribute data (like raw status codes for windows and doors) into discrete, easy-to-use binary sensors. This normalized data feeds into a central automation (notify_car_status_glc), which evaluates state changes—such as a charging cable connection or a low fluid warning—and routes the appropriate message priority to the user through the notify_smart_master script.
sequenceDiagram
participant Mercedes as Mercedes Cloud
participant Integration as HA Integration (mbapi2020)
participant Package as Car Package
participant User as User (Notification)
Note over Arrow: Polling Cycle
Mercedes->>Integration: Vehicle Status Update
Integration->>Package: Update Entity Attributes (Windows, Locks, Odometer)
Package->>Package: Normalize Attributes to Binary Sensors
Note over Package: Automation Logic
alt Critical Warning (e.g., Low Brake Fluid)
Package->>User: 🚨 Critical Alert via script.notify_smart_master
else Standard Event (e.g., Charging Started)
Package->>User: ⚡ Info Notification (Power & Est. Time)
end
Note over User: User Action
User->>Package: Toggle "Pre-entry A/C"
Package->>Integration: Call Service (preheat_start)
Integration->>Mercedes: Send CommandConfiguration (Source Code)
# ------------------------------------------------------------------------------
# Package: Car GLC
# Version: 2.0.3
# Description: Unified logic for Mercedes GLC. Normalizes sensors (Windows/Doors), wrapper switches, and Status Notifications.
# Dependencies:
# - Integration: ReneNulschDE/mbapi2020 (HACS)
# - Script: script.notify_smart_master
# ------------------------------------------------------------------------------
# ==============================================================================
# 1. TEMPLATE SENSORS & BINARY SENSORS
# ==============================================================================
template:
- binary_sensor:
# --- Windows (Normalized from Attribute) ---
- name: "Car GLC Window Front Left"
unique_id: car_glc_window_front_left
device_class: window
state: >
{{ state_attr('binary_sensor.[LICENSE_PLATE]_windows_closed', 'Windowstatusfrontleft') != '2' }}
- name: "Car GLC Window Front Right"
unique_id: car_glc_window_front_right
device_class: window
state: >
{{ state_attr('binary_sensor.[LICENSE_PLATE]_windows_closed', 'Windowstatusfrontright') != '2' }}
- name: "Car GLC Window Rear Left"
unique_id: car_glc_window_rear_left
device_class: window
state: >
{{ state_attr('binary_sensor.[LICENSE_PLATE]_windows_closed', 'Windowstatusrearleft') != '2' }}
- name: "Car GLC Window Rear Right"
unique_id: car_glc_window_rear_right
device_class: window
state: >
{{ state_attr('binary_sensor.[LICENSE_PLATE]_windows_closed', 'Windowstatusrearright') != '2' }}
# --- Doors (Normalized from Attribute) ---
- name: "Car GLC Door Front Left"
unique_id: car_glc_door_front_left
device_class: door
state: >
{{ state_attr('sensor.[LICENSE_PLATE]_lock', 'Door front left') != 'closed' }}
- name: "Car GLC Door Front Right"
unique_id: car_glc_door_front_right
device_class: door
state: >
{{ state_attr('sensor.[LICENSE_PLATE]_lock', 'Door front right') != 'closed' }}
- name: "Car GLC Door Rear Left"
unique_id: car_glc_door_rear_left
device_class: door
state: >
{{ state_attr('sensor.[LICENSE_PLATE]_lock', 'Door rear left') != 'closed' }}
- name: "Car GLC Door Rear Right"
unique_id: car_glc_door_rear_right
device_class: door
state: >
{{ state_attr('sensor.[LICENSE_PLATE]_lock', 'Door rear right') != 'closed' }}
- name: "Car GLC Deck Lid"
unique_id: car_glc_deck_lid
device_class: opening
state: >
{{ state_attr('sensor.[LICENSE_PLATE]_lock', 'Deck lid') != 'closed' }}
# --- Locks (Normalized from Attribute) ---
- name: "Car GLC Lock Front Left"
unique_id: car_glc_lock_front_left
device_class: lock
state: >
{{ state_attr('sensor.[LICENSE_PLATE]_lock', 'Door lock front left') != 'locked' }}
- name: "Car GLC Lock Front Right"
unique_id: car_glc_lock_front_right
device_class: lock
state: >
{{ state_attr('sensor.[LICENSE_PLATE]_lock', 'Door lock front right') != 'locked' }}
- name: "Car GLC Lock Rear Left"
unique_id: car_glc_lock_rear_left
device_class: lock
state: >
{{ state_attr('sensor.[LICENSE_PLATE]_lock', 'Door lock rear left') != 'locked' }}
- name: "Car GLC Lock Rear Right"
unique_id: car_glc_lock_rear_right
device_class: lock
state: >
{{ state_attr('sensor.[LICENSE_PLATE]_lock', 'Door lock rear right') != 'locked' }}
- name: "Car GLC Gas Lock"
unique_id: car_glc_gas_lock
device_class: lock
state: >
{{ state_attr('sensor.[LICENSE_PLATE]_lock', 'Gas lock') != 'locked' }}
# --- Logic Sensors (Consolidated Status) ---
- name: "Car Charge Plug"
unique_id: car_charge_plug
device_class: plug
state: >
{% set value = state_attr('sensor.[LICENSE_PLATE]_range_electric', 'chargingstatus') | float(0) %}
{{ value != 3 }}
icon: >
{% set value = state_attr('sensor.[LICENSE_PLATE]_range_electric', 'chargingstatus') | float(0) %}
{% if value == 3 %}
mdi:power-plug-off
{% else %}
mdi:power-plug
{% endif %}
- name: "Car Charging"
unique_id: car_charging_active
device_class: power
state: >
{% set value = states('sensor.[LICENSE_PLATE]_charging_power') | float(0) %}
{{ value != 0 }}
icon: >
{% if states('sensor.[LICENSE_PLATE]_charging_power') | float(0) == 0 %}
mdi:power-off
{% else %}
mdi:power-on
{% endif %}
- name: "Car Engine"
unique_id: car_engine_status
device_class: running
state: >
{% set value = states('sensor.[LICENSE_PLATE]_ignition_state') | float(0) %}
{{ value >= 2 }}
icon: >
{% if states('sensor.[LICENSE_PLATE]_ignition_state') | float(0) < 2 %}
mdi:engine-off
{% else %}
mdi:engine
{% endif %}
- name: "Car Doors"
unique_id: car_doors_status
device_class: door
state: >
{% set value = state_attr('sensor.[LICENSE_PLATE]_lock', 'doorStatusOverall') %}
{{ value == 0 }}
icon: >
{% if state_attr('sensor.[LICENSE_PLATE]_lock', 'doorStatusOverall') == 0 %}
mdi:car-door
{% else %}
mdi:car-door-lock
{% endif %}
- sensor:
- name: "Car Charge Ready"
unique_id: car_charge_ready_time
state: >
{% set end = state_attr('sensor.[LICENSE_PLATE]_range_electric', 'endofchargetime') %}
{% if end %}
{{ as_datetime(end).strftime('%H:%M') }}
{% else %}
unknown
{% endif %}
# ==============================================================================
# 2. SWITCHES (Wrappers for API Calls)
# ==============================================================================
- switch:
- name: "Car Pre-entry A/C"
unique_id: car_pre_entry_ac
icon: mdi:air-conditioner
state: "{{ is_state_attr('sensor.[LICENSE_PLATE]_range_electric', 'precondNow', 1) }}"
turn_on:
service: mbapi2020.preheat_start
data:
type: "0"
vin: !secret [REDACTED]
turn_off:
service: mbapi2020.preheat_stop
data:
vin: !secret [REDACTED]
- name: "Car Windows"
unique_id: car_windows
icon: mdi:car-door
state: "{{ is_state('binary_sensor.[LICENSE_PLATE]_windows_closed', 'on') }}"
turn_on:
service: mbapi2020.windows_close
data:
vin: !secret [REDACTED]
turn_off:
service: mbapi2020.windows_open
data:
vin: !secret [REDACTED]
- name: "Car Door Locks"
unique_id: car_doors
icon: mdi:car-door
state: "{{ is_state('sensor.[LICENSE_PLATE]_lock', '2') }}"
turn_on:
service: mbapi2020.doors_unlock
data:
vin: !secret [REDACTED]
turn_off:
service: mbapi2020.doors_lock
data:
vin: !secret [REDACTED]
# ==============================================================================
# 3. AUTOMATION (Notifications)
# ==============================================================================
automation:
- alias: "Notify: Car Status"
id: notify_car_status_glc
description: "Manages mobile notifications for critical car events including charging status, pre-conditioning, tire pressure warnings, and fluid levels. Uses the 'notify_smart_master' script."
trigger:
- entity_id: binary_sensor.car_charge_plug
from: "off"
to: "on"
id: plug_in
platform: state
- entity_id: binary_sensor.[LICENSE_PLATE]_charging_active
from: "off"
to: "on"
id: charging_start
platform: state
- entity_id: sensor.[LICENSE_PLATE]_state_of_charge
above: 99
id: charging_full
platform: numeric_state
- entity_id: binary_sensor.[LICENSE_PLATE]_preclimate_status
from: "off"
to: "on"
id: climate_started
platform: state
- entity_id: binary_sensor.[LICENSE_PLATE]_preclimate_status
from: "on"
to: "off"
id: climate_stopped
platform: state
- entity_id: binary_sensor.[LICENSE_PLATE]_tire_warning
to: "on"
id: warn_tire
platform: state
- entity_id: binary_sensor.[LICENSE_PLATE]_low_brake_fluid_warning
to: "on"
id: warn_brake
platform: state
- entity_id: binary_sensor.[LICENSE_PLATE]_low_coolant_level_warning
to: "on"
id: warn_coolant
platform: state
- entity_id: binary_sensor.[LICENSE_PLATE]_low_wash_water_warning
to: "on"
id: warn_wash_water
platform: state
action:
- choose:
- conditions:
- condition: trigger
id: charging_start
sequence:
- wait_for_trigger:
- entity_id: sensor.[LICENSE_PLATE]_charging_power
above: 0
platform: numeric_state
timeout: "00:02:00"
continue_on_timeout: true
- variables:
notification_data: |
{% if trigger.id == 'plug_in' %}
{
"title": "🔌 Car Connected",
"message": "Charging cable connected.",
"tag": "car_charging",
"critical": false
}
{% elif trigger.id == 'charging_start' %}
{% set power = states('sensor.[LICENSE_PLATE]_charging_power') %}
{% set raw_end = state_attr('sensor.[LICENSE_PLATE]_end_of_charge', 'original_value') %}
{# Convert raw timestamp to HH:MM format (Local Time) #}
{% if raw_end not in ['unknown', 'unavailable', None] %}
{% set end_time = as_timestamp(raw_end) | timestamp_custom('%H:%M') %}
{% else %}
{% set end_time = 'Calculating...' %}
{% endif %}
{
"title": "⚡ Car Charging Started",
"message": "Charging at {{ power }} kW. Ready by: {{ end_time }}",
"tag": "car_charging",
"critical": false
}
{% elif trigger.id == 'charging_full' %}
{% set range = states('sensor.[LICENSE_PLATE]_range_electric') %}
{
"title": "🔋 Car Fully Charged",
"message": "Battery is 100%. Range: {{ range }} km.",
"tag": "car_charging",
"critical": false
}
{% elif trigger.id == 'climate_started' %}
{
"title": "🚗 Car Climate",
"message": "Pre-conditioning has started.",
"tag": "car_climate",
"critical": false
}
{% elif trigger.id == 'climate_stopped' %}
{
"title": "🚗 Car Climate",
"message": "Pre-conditioning finished.",
"tag": "car_climate",
"critical": false
}
{% elif trigger.id == 'warn_tire' %}
{
"title": "⚠️ Car Warning",
"message": "Check Tire Pressure!",
"tag": "car_warning",
"critical": false
}
{% elif trigger.id == 'warn_brake' %}
{
"title": "🚨 Car Critical",
"message": "Low Brake Fluid Warning! Check immediately.",
"tag": "car_warning",
"critical": true
}
{% elif trigger.id == 'warn_coolant' %}
{
"title": "⚠️ Car Warning",
"message": "Low Coolant Level.",
"tag": "car_warning",
"critical": true
}
{% elif trigger.id == 'warn_wash_water' %}
{
"title": "💧 Car Warning",
"message": "Low Washer Fluid Level.",
"tag": "car_warning",
"critical": false
}
{% endif %}
- service: script.notify_smart_master
data:
category: car
title: "{{ (notification_data | from_json).title }}"
message: "{{ (notification_data | from_json).message }}"
tag: "{{ (notification_data | from_json).tag }}"
critical: "{{ (notification_data | from_json).critical }}"
mode: queued
# ------------------------------------------------------------------------------
# Changelog
# ------------------------------------------------------------------------------
# 2.0.3 (2025-12-07): Added Changelog footer.
# 2.0.2 (2025-12-07): Added unique_id to automation for UI editing.
# 2.0.1 (2025-12-07): Moved VIN to secrets. Updated automation description.
# 2.0.0 (2025-12-07): Initial consolidation of Package A, B, and UI Automation.
# ------------------------------------------------------------------------------
