Package: Dishwasher
Version: 1.1.0
Description: Logic, sensors, flags, and automations for the LG Dishwasher. Handles normalization of LG ThinQ data, maintenance reminders, and leak detection.
Executive Summary
The Dishwasher package provides comprehensive integration for LG ThinQ dishwashers. It normalizes device states into user-friendly status messages (e.g., 'Running', 'Clean'), calculates human-readable remaining times, and manages maintenance schedules. Critical safety features include leak detection using an external sensor, triggering immediate alarms. This package ensures the dishwasher is not just a monitored appliance but an active participant in the smart home ecosystem.
Process Description (Non-Technical)
How It Works
- Activity Monitoring: The system automatically detects when the dishwasher is powered on or running. It updates the status to "Active", making it visible on your dashboards.
- Cycle Notifications:
- Started: When you start a cycle, you'll receive a notification on your phone estimating when the dishes will be ready.
- Finished: Once the cycle is complete, a "Dishes are Clean" notification arrives, detailing how long the cycle took.
- Maintenance Reminders: The system tracks when a "Machine Clean" cycle is recommended by the manufacturer and flags it on your dashboard until you run the cleaning cycle.
- Leak Protection: Just like the smart water valve, this package monitors a dedicated leak sensor under the dishwasher. If water is detected, a critical alarm is triggered to prevent damage.
Dashboard Connections
This package powers the following dashboard views:
- Home: The Home dashboard serves as the central information hub. It features a large clock and family calendars, alongside detailed weather forecasts. Key home stats are highlighted, including real-time energy prices, power usage, and the status of major appliances like the dishwasher and washing machine. The view also provides a high-level overview of the entire house, displaying camera feeds and status summaries for all key rooms (Sauna, Bathroom, Bedroom, etc.) using 'Streamline' area cards. (Uses 2 entities)
- Kitchen: This view offers comprehensive control over the Kitchen. It monitors critical appliances, showing the status of the fridge (door/leak), coffee machine, and detailed cycle information for the dishwasher. Lighting controls allow for general switching or individual bulb adjustments. A key feature is the visualization of zoned presence detection (Entrance, Table, Cooking) using FP2 sensors, enabling highly granular kitchen automations. (Uses 6 entities)
Architecture Diagram
The system operates on an event-driven model. When the LG Dishwasher updates its Internal State, Home Assistant immediately normalizes this into a uniform Dishwasher Active binary sensor. If the cycle is 'Running', the system calculates the estimated completion time and notifies the users. A parallel logic stream monitors the Leak Sensor continuously; if water is detected, it bypasses the standard notification queue and triggers an immediate 'Critical Alarm' to the mobile app, ensuring rapid response to potential flooding.
sequenceDiagram
participant Dishwasher as LG Dishwasher
participant HA as Home Assistant
participant User as User (Mobile)
participant Leak as Leak Sensor
Dishwasher->>HA: Status Change (Initial -> Running)
HA->>HA: Normalize Status & Calculate Time
HA->>User: Notify "Dishwasher Started" (Est. Time)
Dishwasher->>HA: Status Change (Running -> End)
HA->>User: Notify "Dishes are Clean" (Run Time)
Dishwasher->>HA: Maintenance Signal (Machine Clean)
HA->>HA: Set Flag 'Dishwasher Needs Cleaning'
loop Until Cleaned
HA->>User: Dashboard Alert
end
Dishwasher->>HA: Cycle 'Machine Clean' Started
HA->>HA: Clear Flag 'Dishwasher Needs Cleaning'
Leak->>HA: Water Detected (On)
HA->>User: CRITICAL ALARM "Leak Detected!"Configuration (Source Code)
# ------------------------------------------------------------------------------
# Package: Dishwasher
# Version: 1.1.0
# Description: Logic, sensors, flags, and automations for the LG Dishwasher. Handles normalization of LG ThinQ data, maintenance reminders, and leak detection.
# Dependencies:
# - Integration: LG ThinQ (SmartThinQ LGE Sensors)
# - Entity: binary_sensor.kitchen_dishwasher_leak_sensor_water_leak
# - Script: script.notify_smart_master
# ------------------------------------------------------------------------------
# ==============================================================================
# 1. HELPERS
# ==============================================================================
input_boolean:
# Flag: Tracks if the 'Machine Clean' cycle is due.
# Logic:
# - Turned ON by automation when 'binary_sensor.dishwasher_machine_clean_reminder' goes high.
# - Turned OFF by automation when a 'machine_clean' cycle is actually started.
dishwasher_needs_cleaning:
name: "Dishwasher Needs Cleaning"
icon: mdi:spray-bottle
# ==============================================================================
# 2. TEMPLATE SENSORS (Normalize the LG Data)
# ==============================================================================
template:
- binary_sensor:
- name: "Dishwasher Active"
unique_id: dishwasher_active_normalized
state: >
{{ states('sensor.dishwasher_current_status') not in ['unavailable', 'unknown', 'initial', 'power_off'] }}
icon: mdi:dishwasher
- name: "Dishwasher Door Open"
unique_id: dishwasher_door_normalized
device_class: door
state: >
{{ is_state('binary_sensor.dishwasher_door', 'on') }}
- sensor:
- name: "Dishwasher Status Clean"
unique_id: dishwasher_status_clean
icon: mdi:dishwasher
state: >
{% set status = states('sensor.dishwasher_current_status') %}
{% if status in ['unavailable', 'unknown', 'power_off'] %}
Off
{% else %}
{{ status | replace('_', ' ') | title }}
{% endif %}
- name: "Dishwasher Remaining Time Human"
unique_id: dishwasher_remaining_time_human
icon: mdi:timer-outline
state: >
{% set finish_time = states('sensor.dishwasher_remaining_time') %}
{% if finish_time in ['unavailable', 'unknown', 'none'] %}
--:--
{% else %}
{# Calculate difference between finish time and now #}
{% set time_diff = as_timestamp(finish_time) - as_timestamp(now()) %}
{% if time_diff > 0 %}
{# Convert seconds to H:MM #}
{{ time_diff | timestamp_custom('%-H:%M', false) }}
{% else %}
0:00
{% endif %}
{% endif %}
# ==============================================================================
# 3. AUTOMATIONS
# ==============================================================================
automation:
# --- DISHWASHER STARTED ---
# Notify when the dishwasher starts, with a wait for the time remaining sensor.
- alias: "Notify: Dishwasher Started"
id: notify_dishwasher_started_pkg
description: Notify when dishwasher starts a cycle, waiting for time remaining to be available.
trigger:
- entity_id: sensor.dishwasher_current_status
from: initial
to: running
platform: state
- entity_id: sensor.dishwasher_current_status
from: power_off
to: running
platform: state
action:
# Wait up to 2 minutes for a valid time from the sensor.
- wait_for_trigger:
- platform: template
value_template: >
{{ states('sensor.dishwasher_remaining_time_human') not in ['unknown', 'unavailable', '--:--'] }}
timeout:
minutes: 2
continue_on_timeout: true
- service: script.notify_smart_master
data:
category: info
title: 💦 Dishwasher Started
# Use a conditional message in case the wait timed out.
message: >
{% set remaining = states('sensor.dishwasher_remaining_time_human') %}
{% if remaining not in ['unknown', 'unavailable', '--:--'] %}
Cycle: {{ states('sensor.dishwasher_current_cycle') | replace('_', ' ') | title }}
Ready in: {{ remaining }} hours.
{% else %}
Dishwasher started. Time remaining not yet available.
{% endif %}
tag: dishwasher
clickAction: /lovelace/kitchen
mode: single
# --- DISHWASHER DONE ---
# Notify when dishwasher finishes. Triggers if door opens while status is 'end'.
- alias: "Notify: Dishwasher Done"
id: notify_dishwasher_done_pkg
description: Notify when dishwasher finishes, including run time.
trigger:
- entity_id: sensor.dishwasher_current_status
to: end
id: cycle_end
platform: state
- entity_id: binary_sensor.dishwasher_door
from: "off"
to: "on"
id: door_open
platform: state
condition:
- condition: or
conditions:
- condition: trigger
id: cycle_end
- condition: and
conditions:
- condition: trigger
id: door_open
- condition: state
entity_id: sensor.dishwasher_current_status
state: end
action:
# Calculate run time, handling unknown values safely.
- variables:
run_time_raw: "{{ states('sensor.dishwasher_total_time') }}"
run_time: |-
{% if run_time_raw not in ['unknown', 'unavailable', 'none'] %}
{{ run_time_raw }} min
{% else %}
Unknown time
{% endif %}
- service: script.notify_smart_master
data:
category: info
title: ✨ Dishes are Clean
message: "The cycle has finished. Total run time: {{ run_time }}."
tag: dishwasher
clickAction: app://com.lgeha.nuts
actions:
- action: URI
title: Open LG App
uri: app://com.lgeha.nuts
mode: single
# --- DISHWASHER MAINTENANCE ---
# Alerts when machine clean is needed and resets the flag when a clean cycle is started.
- alias: "Notify: Dishwasher Maintenance"
id: notify_dishwasher_maintenance_pkg
description: Alerts when machine clean is needed and resets when done.
trigger:
- entity_id: binary_sensor.dishwasher_machine_clean_reminder
to: "on"
id: needs_clean
platform: state
- entity_id: sensor.dishwasher_current_cycle
to: machine_clean
id: clean_cycle_started
platform: state
action:
- choose:
# Case 1: Reminder turns ON and we haven't acknowledged it yet.
- conditions:
- condition: trigger
id: needs_clean
- condition: state
entity_id: input_boolean.dishwasher_needs_cleaning
state: "off"
sequence:
- service: input_boolean.turn_on
target:
entity_id: input_boolean.dishwasher_needs_cleaning
- service: script.notify_smart_master
data:
category: info
title: 🧼 Dishwasher Maintenance
message: The dishwasher needs a Machine Clean cycle.
tag: dishwasher_maintenance
sticky: true
# Case 2: A 'machine_clean' cycle is started, so we reset the flag.
- conditions:
- condition: trigger
id: clean_cycle_started
sequence:
- service: input_boolean.turn_off
target:
entity_id: input_boolean.dishwasher_needs_cleaning
mode: single
# --- DISHWASHER LEAK DETECTION ---
# Critical alarm if the external leak sensor detects water.
- alias: "Notify: Dishwasher Leak"
id: notify_dishwasher_leak_pkg
description: Critical alarm triggered by the kitchen leak sensor.
trigger:
- platform: state
entity_id: binary_sensor.kitchen_dishwasher_leak_sensor_water_leak
to: "on"
action:
- service: script.notify_smart_master
data:
category: alarm
title: "💧 Dishwasher Leak Detected!"
message: "CRITICAL: Water detected under the dishwasher. Check immediately!"
tag: dishwasher_leak
critical: true
sticky: true
clickAction: /lovelace/kitchen
mode: single
# ------------------------------------------------------------------------------
# Changelog
# ------------------------------------------------------------------------------
# 1.1.0 (2025-12-09): Added critical leak detection automation.
# 1.0.0 (2025-12-07): Initial package creation with status, time logic, and maintenance reminders.
# ------------------------------------------------------------------------------
